YH-1325 Large Area Laser Cutting Machine

Processing Area: 1300mm*2500mm Power: 100W/120W/150W/180W Color: Blue-white Applicable materials: acrylic sheet, wood, paper, leather, cloth, plastic, rubber, resin, ceramic tiles,bamboo, shellfish, ABS sheet.
Color:
Availability:
Quantity:
  • YH-1325

  • Yuehua

  • YH-1325

Advantages:

1. 64DSP high-speed processor.

2. Windows USB / U disk port supported.

3. Larger offline storage.

4. Simple regulation of laser power.

5. Exquisite circuit design.

6. True color screen and AWC708C latest control system. RUIDA is also available.

7. Laser tube is produced by our own factory.


Technical Parameters:

Model

YH-1325

Processing area

1300*2500mm

Laser power

100W, 120W,150W, 180W

Cutting speed

0-10000mm/min

Engraving speed

0-64000mm/min

Repeatability

0.01mm.

Graphic format

AI,CDR,BMP, JPG, DST, PLT, DXF, DWG, TIFF, PSD

Supported software

Coreldraw, Photoshop, AutoCAD

The smallest cutting characters

Character: 2.0*2.0mm    English:1.0*1.0mm

Operating temperature

0-45°C.

machine samples

shipping
